U-BOLTS
U-BOLTS
Part Number |
Dia ØA |
Dim. B |
Dim. C |
| 42-01 | 7/16" | 2" | 6" |
| 42-02 | 7/16" | 2-7/8" | 7-3/4" |
| 42-03 | 7/16" | 3" | 7-1/2" |
| 42-04 | 1/2" | 2-1/2" | 8-1/4" |
| 42-05 | 1/2" | 2-7/8" | 7" |
| 42-06 | 1/2" | 3" | 8" |
| 42-07 | 9/16" | 3" | 8-1/4" |
| 42-08 | 9/16" | 3-1/4" | 8" |
| 42-09 | 9/16" | 3-3/8" | 12" |
| 42-10 | 5/8" | 3" | 8-1/2" |
| 42-11 | 5/8" | 3-1/4" | 8-1/4" |
| 42-12 | 5/8" | 3-1/4" | 12" |
U-BOLTS
U-BOLTS
Part Number |
Dia ØA |
Dim. B |
Dim. C |
| 42-21 | 3/8" | 2-1/2" | 2-1/2" |
| 42-22 | 3/8" | 7" | 7" |
| 42-23 | 1/2" | 3" | 4" |
| 42-24 | 5/8" | 4" | 4" |
| 42-25 | 5/8" | 4" | 5-1/2" |
| 42-26 | 5/8" | 4" | 7-1/2" |
| 42-27 | 5/8" | 5" | 8-1/2" |
| 42-28 | 5/8" | 6" | 8" |
| 42-29 | 5/8" | 7" | 5" |
| 42-30 | 5/8" | 7" | 7" |
| 42-31 | 5/8" | 7" | 8-1/2" |
| 42-32 | 3/4" | 5" | 7" |
| 42-33 | 3/4" | 7" | 8-1/2" |
| 42-34 | 3/4" | 7" | 7" |
U-BOLTS
U-BOLTS (METRIC)
Part Number |
Dia ØA |
Dim. B |
Dim. C |
Dim. D |
| 42-51 | 11.00 / 0.43" | 70.00 / 2.76" | 37.00 / 1.46" | 42.00 / 1.65" |
| 42-52 | 12.80 / 0.50" | 82.00 / 3.23" | 39.00 / 1.54" | 49.00 / 1.93" |
| 42-53 | 11.00 / 0.43" | 90.00 / 3.54" | 30.00 / 1.18" | 56.00 / 2.20" |
| 42-54 | 15.00 / 0.59" | 96.00 / 3.78" | 52.00 / 2.05" | 60.50 / 2.38" |
